PowerHub
600 kW–1.2 MW
PowerHub consolidates bulk power away from traffic lanes and dynamically routes 600 kW to 1.2 MW from four input classes: utility grid, solar, battery energy storage (BESS), and generation capacity. One hub feeds up to 12 satellite charging dispensers over the PowerFlex subterranean network.
Centralized dynamic power management
Power envelope600 kW–1.2 MW
SatellitesUp to 12 satellites
Inputs4 input classes
Reliability99% uptime target
Applications
PowerHub is the permanent charging architecture driving Volatus' technology suite: one centralized dynamic power management (DPM) hub that scales from kilowatts to megawatts and feeds high-density satellite dispensers across the site. Meridian Cloud handles tracking, monitoring, and optimization above it.
- Centralized DPM that dynamically routes 600 kW–1.2 MW from four input classes
- Feeds up to 12 satellite dispensers over the PowerFlex subterranean network
- Architecture designed to cut civil costs up to 30% and reclaim up to 60% of site footprint
- Engineered toward a 99% uptime target with redundant architecture and predictive diagnostics
Fleet depots scaling past standalone chargersHigh-density public charging plazasTransit and logistics hubsMegawatt-class charging programs
Best fit
Sites that need more charging positions from one power architecture
Programs planning a phased path from hundreds of kilowatts to megawatts
Operators consolidating utility, solar, and storage inputs into one architecture
Technical specifications
Specifications reflect current Volatus product documentation (July 2026); final values are confirmed during project configuration. Design-analysis figures reflect Volatus engineering models for reference configurations.
Power architecture
| Envelope | Dynamically routes 600 kW–1.2 MW via centralized dynamic power management (DPM) |
|---|---|
| Input classes | Utility grid (3-phase 480 VAC), solar, BESS, and generation capacity |
| Scaling | kW to MW via 30 kW modules, with live module swapping |
| Megawatt path | Megawatt charging system (MCS)-ready architecture |
Satellite distribution
| Dispensers | Powers up to 12 x 100 kW satellite DC fast charging dispensers |
|---|---|
| Routing | PowerFlex subterranean network, hardwired sub-surface energy routing |
| Voltage behavior | Engineered to minimize voltage drop across extended runs |
| Interface | Terminal Box power distribution interface |
Site design
| Placement | Consolidates bulk power away from traffic lanes |
|---|---|
| Civil work | Designed to cut civil costs up to 30% (Volatus design analysis) |
| Footprint | Designed to reclaim up to 60% of site footprint via satellites (Volatus design analysis) |
| Lane clutter | Sub-surface routing removes lane clutter |
| Availability | Built to order; configuration confirmed during project scoping |
Lifecycle support
- Remote diagnostics and operational visibility
- Preventive and corrective maintenance planning
- Site-advantage assessment for placement, power, and footprint
- Configuration and expansion review as site demand changes
FAQ
01What is PowerHub?
PowerHub is the Volatus centralized charging architecture: a dynamic power management hub that routes 600 kW to 1.2 MW from utility, solar, BESS, and generation-capacity inputs to up to 12 satellite charging dispensers.
02What is PowerFlex?
PowerFlex is the subterranean infrastructure network that carries power from the PowerHub to satellite dispensers through hardwired sub-surface routing. It is engineered to minimize voltage drop across extended runs while removing lane clutter.
03How does the architecture lower site costs?
By consolidating power conversion in one hub and feeding compact satellite dispensers, the architecture is designed to cut civil costs up to 30% and reclaim up to 60% of site footprint compared with equivalent standalone-charger builds, per Volatus design analysis.
04How does PowerHub scale over time?
Capacity scales from kilowatts to megawatts through 30 kW modules with live module swapping. The architecture is Megawatt Charging System (MCS) ready, so a site can grow toward megawatt charging without replacing the foundation.
